Grade & its Properties

Our Products

GRADE	C% (MAX)	MN% (MAX)	S% (MAX)	P% (MAX)	SI% (MAX)	NI%	CR%	N% (MAX)	CU%	TS (MIN)	YS (MIN)	EL% (MIN)	HARDNESS (HV)
J1	0.12	10.7	0.01	0.1	0.75	0.80-1.30	13.25-14.25	0.2	0.6-0.9	750	350	40	245 max
J3	0.13	10.7	0.01	0.1	0.75	0.80-1.30	13.25-14.35	0.2	0.5-0.8	750	350	40	245 max
J-4	0.1	10	0.01	0.08	0.75	1.00-2.00	15.00-16.00	0.2	1.5-2.0	650	325	40	245 max
201	0.15	7.5	0.03	0.06	1	3.50-5.50	16.00-18.00	0.25		655	310	40	245 max
202- 4%	0.15	10	0.03	0.06	1	4.00-6.00	17.00-19.00	0.25		620	260	40	245 max
204CU	0.1	9	0.01	0.06	0.75	1.50-3.50	16.00-17.50	0.2	2.0-4.0	620	310	40	245 max

GRADE	C% (MAX)	MN% (MAX)	S% (MAX)	P% (MAX)	SI% (MAX)	NI%	CR%	MO%	N% (MAX)	TS (MIN)	YS (MIN)	EL% (MIN)	HARDNES S (HV)
301	0.15	2	0.03	0.045	1	6.00-8.00	16.00-18.00		0.1	515	205	50	220 max
304	0.07	2	0.03	0.045	0.75	8.00-10.50	17.50-19.50		0.1	515	205	50	205 max
304L	0.03	2	0.03	0.045	0.75	8.00-12.00	17.50-19.50		0.1	485	170	40	205 max
316	0.08	2	0.03	0.045	0.75	10.00-14.00	16.00-18.00	2.0-3.0	0.1	515	205	53	220 max
316L	0.03	2	0.03	0.045	0.75	10.00-14.00	16.00-18.00	2.0-3.0	0.1	485	170	53	220 max

GRADE	C% (MAX)	MN% (MAX)	S% (MAX)	P% (MAX)	SI% (MAX)	NI%	CR%	N% (MAX)	OTHERS	TS (MIN)	YS (MIN)	EL% (MIN)	HARDNESS (HV)
430	0.12	1	0.03	0.04	1	0.75 max	16.00-18.00			450	205	22	185 max
409L	0.03	1	0.03	0.04	1	0.50 max	10.50-11.70	0.03	Ti-0.75 max	380	170	20	185 max
441	0.03	1	0.015	0.04	1		17.50-18.50		Ti-0.6 max	430	250	18	185 max
410	0.15	1	0.03	0.04	1	0.75 max	11.50-13.50			450	205	20	230 max
(Blade Steel)		1		0.03						758
